Introducing the LLHB4 Series Linear High Bay, a versatile lighting solution for industrial and commercial settings. This product is ideal for replacing conventional HID and fluorescent systems, offering high efficiency and flexibility in large indoor spaces.

Key Features and Benefits

High Quality LED Chips for Efficiency and Heat Dissipation
Polycarbonate Lens with High Flame Retardant Point
Multi-Power and Dimmable (0~10V)
Color Temperatures: 4000K and 5000K
Surge Protector and Steel Housing
Pre-installed Sensor Ready Audio Jack
Operating Temperature: -4°F ~ 131°F
Suitable for Damp Locations
50,000 Hours Rated Life and 5-Year Warranty

Specifications

Wattage: 300W
Lumens: 20400LM/30600LM/40800LM
Voltage: 120~277VAC
Efficacy: 136 LPW
Color Rendering Index: >80
Wide Beam Angle
Steel Thickness: 24 Gauge

Common Uses

Ideal for manufacturing plants, warehouses, distribution centers, gymnasiums, cold storage, and other large indoor spaces with mounting heights from 10ft to 40ft. Can be surface mounted.

Details

Beam Angle:	H102.3 V103.8°
CRI:	80
Certifications:	UL Listed
Color Temperature:	4000K
Country of Origin:	CHINA
Dimming Type:	0-10V
Efficacy:	125LM/W
Finish / Color:	White
Housing Material:	Steel
IP Rating:	IP20
Item Height (Inch):	2
Item Length (Inch):	46.7
Item Weight (LBS):	18
Item Width (Inch):	17.7
L70 Expected Life (hours):	50,000hr
Lumen Output:	40800\|20400\|30600
Operating Temperature:	-30-+40
Power Factor:	>0.92
Ships From:	CA
THD:	<19
Voltage:	120-277V
Warranty (Years):	5
Wattage:	150W\|225W\|300W
